Polar Bear

SPECIFICATIONS

Opera ng Voltage (V): 100-277 VAC/220-240 VAC/100-130 VAC Luminaire Efficacy(lm/W): 147lm/W
141-392VDC/311-339 VDC/141-184 VDC Ingress Protec on(IP): IP66
Frequency (Hz): 50/60Hz Impact Resistance(IP): IK08
Power Consump on (W): 80W/120W/160W/200W/240W Beam Angle: 15°, 60°, 80°, 120°
SL(C0-180°;90°;90-270°;150°)
Connec ng Terminals: 3*1.0-4mm²(L+N+PE)
Correlated color Temp (CCT): 3000±300K - 5700±300K Cable Entries: 2XNPT 3/4”
Colour Rendering Index (CRI): 70 (M20*1.5, M25*1.5)
Total Harmonic Distor ons (THD): <10% Earthing Protec on: M4 Earth Bolts
Power Factor (PF): >0.98 Lifespan: >50 000hrs
Insula on Class: Class I LED Type: SMD
Opera ng Temp: -40°C ~ +55°C (T5) Driver Type: Meanwell
Surge Protec on Op onal: Op onal Moun ng Op ons: Pendant, Pipe
LED Driver: Stanchion, Pole

MATERIAL STRUCTURE
Enclosure Material: Copper Free Aluminium Housing Colour: Orange RAL2011
Exposed Fastener: Stainless Steel 316 Grey RAL7040 - Op onal
Protec ve Cover: Tempered Glass,Stand 7J impact Coa ng: Epoxy Powder Coa ng

ORDERING INFORMATION

XXX XXX XXX XXX XXX XXX X X XXX XXX XXX XXX X X

Product Family Product ID Size(mm) Power Efficency CCT IP IK Beam Angle Cable Entry Moun ng Control Type CRI Surge

Ex Floodlight Polar Bear 210*400*161 80W(80W) 147lm/W 3000K(03) IP66 IK08 15° NPT 3/4” Pipe Clamp Standard 70(7) 4KV
(EFLD) (POB) (241) (147LPW) 4000K(04) (IP66) (IK08) (15Deg) (NPT) (PIC) (STD) (4KV)
7.3kg 5000K(05) 60° M20*1.5 Buckle Emergency 6KV
5700K(06) (60Deg) (M20) (BUC) (EMG) (6KV)
260*400*161 120W(120W) 80° M25*1.5 Loop
(261) 160W(160W) (80Deg) (M25) (LOP)
11kg 120° Stanchion
(120Deg) Bracket
500*400*161 200W(200W) SL(C0-180°;90°; (ST1)
(541) 240W(240W) 90-270°;150°) Stanchion
18.4kg Bracket
(ST2)
Wire Guard 1
(WG1)
Wire Guard 2
(WG2)
