A Series Ex Floodlight

SPECIFICATIONS - A, A3, A4

Power Consump on (W): 80W 100W 150W 180W 200W 250W 300W 400W
Luminous Flux (lm): 11200lm 14000lm 21000lm 25200lm 28000lm 35000lm 42000lm 56000lm
Input Voltage (V): AC200-250VAC, 50/60Hz Luminaire Efficacy(lm/W): 140lm/W
Power Factor (PF): >0.95 | ≥90% Driver Efficiency L&B Ra ng @55°C: L70> 78 000hrs
Ambient Opera ng Temp: T5: -40°C to +45°C Correlated color Temp (CCT): 2200K - 7000K
T6: -40°C to +40°C Colour Rendering Index (CRI): >70
Beam Angle: 40° | 45° | 60° | 90°
Housing Body: Copper-free Aluminium Dimming: 0-10V / Non Dim
Lens Diffuser: Tempered glass & polycarbonate Ingress Protec on(IP): IP66 | IP67
Hardware: Stainless Steel IK08 - Glass Cover
Fixture Colour: Grey RAL7040 Impact Resistance(IK): IK10 - With Wire Guard
Cable Entry: Side: 3/4 NPT, M20, M25, 1/2NPT Surge Protec on (KV): 4KV - Op onal
Top: 3/4 NPT, M25 Moun ng Op ons: Ceiling, Wall, Hook, Pole
Stanchion

*Cable Entries: For side and top, 3/4 NPT is standard. If others are required please use the correct ordering code below.
ORDERING INFORMATION

XXX XXX XXX XXX XXX XXX X X XXX XXX XXX XXX XXX X

Product Family Product ID Size(mm) Power Efficency CCT IP IK Beam Angle Accessories Housing Moun ng Driver Cable Entry

Ex Floodlight A 320*240*263 80W(80W) 140lm/W 2200K(22) IP66 IK08 40° Lamp Shade Flat Glass Straight Pipe Standard Side 3/4
(EFLD) (A) (322) (140LPW) 3000K(03) (IP66) (IK08) (40D) (LAS) (FLG) (STP) (STD) NPT
7.90kg 100W(100W) 4000K(04) IP67 IK10 45° Cut-Off Lamp Drop Lens Bended Pipe 0-10V (S34)
5000K(05) (IP67) (IK10) (45D) Shade Wireguard (BEP) (DIM) Side M20
6000K(06) 60° (CLS) (DLW) Stanchion Arm (SM2)
A3 380*230*268 150W(150W) 7000K(07)
(A3) (382) 180W(180W) (60D) Junc on Box (STA90) Side M25
10.30kg 90° (JUB) Stanchion Arm (SM5)
200W(200W) (90D) Ex Gland (STA25) Side 1/2
(EXG) Pendant NPT
Emergency (PEN) (S12)
A4 420*300*357 250W(250W) (EMG)
(A4) (433) 300W(300W) Bracket Top 3/4
15.80kg 400W(400W) (BRA) NPT
Hook (T34)
(HOK) Top M25
(T25)
Pole Support
(POS25)
Pole Support
(POS90)
Pendant Chain
(PEC)
Stanchion Arm D
(STAD)
