Portable Forest Frog

TECHNICAL DATA

Rated Voltage (V): 100-277VAC Luminaire Efficacy(lm/W): 136.5 (lm/W)
VDC Unified Glare Index(UGR): >UGR22
Frequency (Hz): 50/60Hz
Power Consump on (W): 10W 15W Impact Protec on (IK): IK08
Correlated color Temp (CCT): 3000K - 6000K Ingress Protec on(IP): IP66
Classifica on: Group II Zone 1 & 21 and 2 & 22
Electrical Class: 1 Beam Angle: 120°
Power Factor (PF): >0.98 Lifespan: 50 000hrs
Colour Rendering (CRI): 70
Opera ng Temp: -20°C + 55°C LED Brand: SMD LED Chipset

Driver: Over Voltage Protec on Earthing Protec on:
Short Circuit Protec on

BATTERY
Ba ery Capacity 4.4 Ah Ba ery Back Up: 10W - 10 Hours
Ba ery Type: Lithium Ba ery 15W - 6 Hours
Ba ery Lifespan: 500 Cycles
Charging Time: 3 Hours

MATERIAL STRUCTURE
Enclosure Material: Die-Cast Aluminium Alloy Housing Colour: Orange
Exposed Fastener: Stainless steel Coa ng: Epoxy powder coa ng
Protec ve Cover: Tempered glass,Stand 7J impact An Corrosion: Op onal

ORDERING INFORMATION

XXX XXX XXXX XXX XXX XXX XXX XXX XXX

Product Family Product ID Size Power Efficacy CCT Control CRI Voltage

Portable Ex Forest Frog 209*198*293mm 10W (10) 136.5lm/W (136) 3000±300K Standard (STD) 70 (7) 100-277VAC
Floodlight Magne c Stand (212) 15W (15) (03)WW VDC
(PEF) (FFM) 6.5kg 4000±300K
(04)NW
Forest Frog 209*236*303mm 5000±300K
Bracket Stand (223) (05)NW
(FFB) 5.2kg 5700±300K
(06)CW
