S10 Streetlight Series

ORDERING INFORMATION

XXX XXX XXXX XXX XXX XXX XXX XXX XXX X

Product Family Product ID Size(mm) Power Efficacy Driver Type Control CCT CRI Surge Protec on

Streetlight ALTSA L463*W108*H140 20W (20W) 130lm/W Meanwell (MNW) Standard (STD) 2700K (02K) 70 (7) 10KV (10KV)
(STL) S10 Streetlight (411) 30W (30W) (130LPW) Moso (MOS) Emergency (EMG) 3500K (03K) 20KV (20KV)
(AS10) 1.26kg 40W (40W) 150lm/W Sosen (SOS) Light Sensor (LIS) 4000K (04K)
(150LPW) Inventronics (IVT) 0-10V (DIM) 4500K (45K)
L467*W175*H140 50W (50W)
(461) 60W (60W) 170lm/W Time Control (TIC) 5000K (05K)
1.65kg 70W (70W) (170LPW) IOT Control (IOT) 6000K (06K)
LMS System (LMS)
L564*W221*H140 80W (80W)
(521) 100W (100W) Daylight Sensor (DAS)
2kg 120W (120W)
L647*W241*H140 150W (150W)
(621) 180W (180W)
2.32kg
L740*W276*H140 200W (200W) Temperature Operating Range -40℃～50℃
(721) 240W (240W) Humidity OperatingRange 20%～95%
2.61kg Storage Temperature Range -40℃～75℃
Storage Humidity Range 10%～80%

DIMENSIONS

20-40W 50-70W 80-120W 150-180W 200-240W
