TANK SERIES

SPECIFICATIONS

Opera ng Voltage (V): 100-277 VAC,20-30 VAC,347-480 VAC Luminaire Efficacy(lm/W): 152lm/W
141-391VDC,491-679 VDC Ingress Protec on(IP): IP66
Frequency (Hz): 50/60Hz Impact Resistance(IP): IK08
Power Consump on (W): 80W/100W/120W(Single lamp) Beam Angle: 40°, 80°, 120°
160W/200W/240W(Two lamps) Lifespan: 50 000hrs
320W/400W/480W(Four lamps) Connec ng Terminals: 3*1.0-4mm²(L+N+PE)
Correlated color Temp (CCT): 3000±300K - 5700±300K Cable Entries: 2XM20*1.5
Colour Rendering Index (CRI): 70 NPT 3/4”,M25*1.5
Total Harmonic Distor ons (THD): <10% Earthing Protec on: M4 Earth Bolts
Power Factor (PF): >0.98
Insula on Class: Class I LED Type: SMD
Opera ng Temp: -40°C ~ +55°C (T5) Driver Type: Meanwell
Surge Protec on Op onal: Op onal Moun ng Op ons: Ceiling
LED Driver: Wall,

MATERIAL STRUCTURE
Enclosure Material: Die Cas ng Aluminium Alloy Housing Colour: Grey RAL7040
Exposed Fastener: Stainless Steel 316 Coa ng: Epoxy Powder Coa ng
Protec ve Cover: Tempered Glass,Stand 7J impact

ORDERING INFORMATION

XXX XXX XXX XXX XXX XXX X X XXX XXX XXX XXX X X

Product Family Product ID Size(mm) Power Efficency CCT IP IK Beam Angle Cable Entry Moun ng Control Type CRI Surge

Ex Floodlight Tank 332*212*142 80W(80W) 152lm/W 3000K(03) IP66 IK08 40° NPT 3/4” Ceiling Standard 70(7) 4KV
(EFLD) (TAK) (321) 100W(100W) (152LPW) 4000K(04) (IP66) (IK08) (40Deg) (NPT) Bracket (STD) (4KV)
8.3kg 120W(120W) 5000K(05) 80° 2XM20*1.5 (CER) Emergency 6KV
5700K(06) (80Deg) (M20) Stanchion (EMG) (6KV)
322*426*142 160W(160W) 120° M25*1.5 Bracket
(ST1)
(341) 200W(200W) (120Deg) (M25)
13kg 240W(240W) Stanchion
Bracket
(ST2)
671*426*142 320W(320W) Stanchion
(641) 400W(400W) Bracket
27kg 480W(480W) (ST4)
