LED Frame Lights

SPECIFICATIONS

Rated Voltage (V): AC184-266V Luminaire Efficacy(lm/W): 100(lm/W)
Frequency (Hz): 50/60Hz Cable Entry: Back
Power Consump on (W): 24-30W 36-42W 48-60W 64W Unified Glare Index(UGR): <UGR22
Correlated color Temp (CCT): 3000K - 6000K L&B Ra ng: L80 B10
Colour Rendering (CRI): 80/90 Ingress Protec on(IP): IP42
Total Harmonic Distor ons (THD): <15% Beam Angle: 110°
Power Factor (PF): >0.95 Lifespan: 50 000hrs
Electrical Class: Class I Moun ng Op ons: Surface
Driver Type: Standard Recessed
LED Brand: SMD 2835 Suspended
Surge Protec on: Opera ng Temp: -20 ~ +50°C
Op onal

MATERIAL STRUCTURE Polycarbonate(PC)isusedwhichissuperiortoeven Poly methyl methacrylate (PMMA)and can carry a life me guaranteeitself
Housing Body: Aluminium Housing Colour: White
Lens Diffuser: Polycarbonate(PC) Lens: Opal

OPTIONAL FEATURES
Dimmable Op ons: DALI-Dimmable 0-10V Triac Dimmable
Emergency Op ons: 20% Back-up Power
Cer fica ons RoHs/IEC/SANS

ORDERING INFORMATION

XXX XXX XXXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX

Product Family Product ID Size Power Efficacy CCT IP Beam Angle Surge Moun ng Kit Driver Control Type CRI

Panel Light Frame Light 300x300(303) 24W (24W) 100lm/W 3000K(03) IP42 110° 2.5KV Surface Standard Standard (STD) 80 (8)
(PAN) (LFL) HOLE (100LPW) 4000K(04) (IP42) (110) (2.5KV) (SURK) (STD) Emergency (EMG) 90 (9)
280*280 5000K(05) Suspended Microwave (MIC)
4KV
600x300(603) 30W (30W) 6000K(06) (4KV) (SUSK) Infrared (INF)
HOLE 36W (36W) Recessed PIR (PIR)
580*280 (REC) Triac (TRI)
600x600(606) 36W (36W) Dali (DAL)
HOLE 42W (42W) 0-10V (DIM)
580*580 48W (48W)
1200x300(123) 48W (48W)
HOLE
1180*280
1200x600(126) 60W (60W)
HOLE
1180*580
Grill Frame 600x600(606) 60W (60W)
(GF/1) HOLE
580*580

Grill Frame 600x600(606) 60W (60W)
(GF/2) HOLE
580*580
