LED Back Lit Panel Light

TECHNICAL DATA

SPECIFICATIONS
Rated Voltage (V): AC200-240V Luminaire Efficacy(lm/W): 50(lm/W)
Frequency (Hz): 50/60Hz 60(lm/W)
Power Consump on (W): 40W 48W 60W Unified Glare Index(UGR): <UGR22
Correlated color Temp (CCT): 2200K - 6000K
Colour Rendering (CRI): 80/90 L&B Ra ng: L80 B10
Total Harmonic Distor ons (THD): <15% Ingress Protec on(IP): IP42 (Standard)
Power Factor (PF): >0.95 IP65 (Op onal)
Electrical Class: Class I Beam Angle: 110°
Opera ng Temp: -20 ~ +50°C Lifespan: 50 000hrs
Moun ng Op ons: Surface
Driver Type: Standard Recessed
LED Type: SMD 2835 Suspended
Surge Protec on:
Op onal Cable Entry: Side

MATERIAL STRUCTURE Polycarbonate(PC)isusedwhichissuperiortoeven Poly methyl methacrylate (PMMA)and can carry a life me guaranteeitself
Housing Body: Cold rolled, Mild steel Housing Colour: White
Frame: Aluminium Lens: Opal
Lens Diffuser: Polycarbonate(PC) An Corrosion: Op onal

OPTIONAL FEATURES
Dimmable Op ons: DALI-Dimmable 0-10V Triac Dimmable
Sensor Op ons: Microwave Mo on PIR Infrared
Emergency Op ons: 20% Back-up Power External
Cer fica ons RoHs/IEC/SANS

ORDERING INFORMATION

XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX XXX

Product Family Product ID Size Power Efficency CCT IP Beam Angle Surge Moun ng Kit Driver Control Type CRI

Panel Light Back Lit 600x600 40W (40W) 50lm/W 2200K(02) IP42 110° 2.5KV Surface Meanwell Standard (STD) 80 (8)
(PAN) Sky Panel (606) 60W (60W) (50LPW) 3000K(03) (IP42) (110) (2.5KV) (SURK) (MNW) Emergency (EMG) 90 (9)
(BLSP) 60lm/W 4000K(04) IP65 4KV Suspended Standard Microwave (MIC)
(60LPW) 5000K(05) (IP65) (4KV) (SUSK) (STD) Infrared (INF)
1200x300 48W (48W) 6000K(06) PIR (PIR)
(123) Recessed Triac (TRI)
(REC)
Dali (DAL)
1200x600 60W (60W) 0-10V (DIM)
(126)
