Swordfish

TECHNICAL DATA SPECIFICATIONS

Rated Voltage (V): 100-277VAC/ 24-48 VAC Rated Voltage Emergency (V): VAC
VDC VDC VDC VDC
Frequency (Hz): 50/60Hz Luminaire Efficacy(lm/W): 136.5(lm/W)
Power Consump on (W): 18, 36, 48, 56, 72W Unified Glare Index(UGR): UGR22 (Standard)
Correlated color Temp (CCT): 2000K - 6000K UGR19 (Op onal)
Colour Rendering (CRI): 70/82 L&B Ra ng: L80 B10
Total Harmonic Distor ons (THD): <10% Impact Protec on (IK): IK08
Power Factor (PF): >0.98 Ingress Protec on(IP): IP66
Electrical Class: Class II / Zone 1 & 21 and 2 & 22 Beam Angle: 120°
Opera ng Temp: -20 ~ +50°C Lifespan: 50 000hrs(Standard)
Surge Protec on: 5 KV 70 000hrs(Op onal)
Driver Type: Standard Vibra on Resistant Brackets: Op onal
LED Brand: Over voltage /short circuit protec on
Connec ng Terminals: Moun ng Op ons: Standchion,Ceiling
Entry & Output Cable: Pendant,Pipe,Clamp
Earthing Protec on: Cable Outer Diameter:
Size (LxWxH)
Weight: (Standard)
Weight: (Emergency)
MATERIAL STRUCTURE
Enclosure Material: Copper-free Aluminium Housing Colour: Orange/Grey
Exposed Fastener: Stainless steel Coa ng: Epoxy powder coa ng
Protec ve Cover: Tempered glass,Stand 7J impact An Corrosion: Op onal

EMERGENCY FEATURES Type B Type C
Ba ery Capacity 2.2 Ah 2.8 Ah
Ba ery Type: Ni-Cd Ni-Cd
Ba ery Lifespan: 500 Cycles 500 Cycles
Back Up: 180 Min 180 Min
Charging Time: 24 Hours 24 Hours
ORDERING INFORMATION

XXX XXX XXXX XXX XXX XXX XXX XXX X

Product Family Product ID Size Power Efficacy Driver Type Control CRI Glare Rate

Explosion Proof Sword Fish 600*136*124mm(606) 18W (0018) 100lm/W (100) Standard Standard (STD) 70 (7) 19 (19)
(Ex) (SF) 36W (0036) 110lm/W (110) Emergency (EMG) 82 (8) 22 (22)
48W (0048) 130lm/W (130)
900*136*124mm(606) 36W (0036)
48W (0048)
56W (0056)
72W (0072)
