BAW & BMW Downlight Series

TECHNICAL DATA

SPECIFICATIONS
Rated Voltage (V): AC184-265V Luminaire Efficacy(lm/W): 100(lm/W)
Frequency (Hz): 50/60Hz 120(lm/W)
Power Consump on (W): 5-7-9W 10-12-15W 15-16-18W 20-24-30-40W Unified Glare Index(UGR): UGR22 (Standard)
Correlated color Temp (CCT): 2700K - 3000K- 4000K- 6000K L&B Ra ng: L90 B10 50 000hrs
Colour Rendering (CRI): 80/90 L70 B10 100 000hrs
Total Harmonic Distor ons (THD): <15% Ingress Protec on(IP): IP54 - BMW SERIES
Power Factor (PF): >0.90 | >0.95 IP20 - BAW SERIES
Electrical Class: Class I Beam Angle: 60° - BAW SERIES
Opera ng Temp: -20 ~ +50°C 45°- 50°- 58° - BMW SERIES
Driver Type: Standard(Constant Current LED Driver) Lifespan: 50 000hrs
LED Type: BAW Series- CREE - COB / SMD 2835 Moun ng Op ons: Recessed
BMW Series- CREE - COB Entry & Output Cable: Back / 20cm (Standard)

MATERIAL STRUCTURE
Housing Body: Die-Cas ng Aluminum Housing Colour: White Ma
Lens: Poly Methyl Methacrylate(PMMA) Black
Silver

OPTIONAL FEATURES
Dimmable Op ons: DALI-Dimmable 0-10V Triac Dimmable
Emergency Op ons: 20% Back-up Power External
Sensor Op ons Microwave Bi-Level

ORDERING INFORMATION(IP54 BAW SERIES)

ΦCUTOUT SIZE(COS) Φ STANDARD SIZE(STD)

XXX XXX XXXX XXX XXX XXX XXX XXX X
Product Family Product ID Size Power Efficacy Driver Type Control CRI Glare Rate
Downlight Brilliance AW Φ75mm(75) 5W (0005) 100lm/W (100) Standard (STD) Standard (STD) 80 (8) 22 (22)
(DWN) Downlight Series Φ80xH40mm(84) 120lm/W (120) Emergency (EMG) 90 (9)
(BAW) Φ85mm(85) 7W (0007)
Φ96xH47mm(94) TRIAC (TRI)
0-10V (DIM)
Φ100mm(100) 9W (0009)
Φ113xH55mm(155) DALI (DAL)
Φ120mm(120) 12W (0012) Microwave (MIC)
Φ138xH64mm(136) Bi-Level (BIL)
Φ140mm(140) 15W (0015)
Φ165xH74mm(167)
Φ170mm(170) 20W (0020)
Φ195xH85mm(198)
Φ200mm(200) 30W (0030)
Φ228xH97mm(297)
